Our Linear Tub Filling Machine can filled Ingredients like nuts, chocolate chips and syrups like chocolate and other flavours mix with variety of ice creams in Sundae Tub gives attractive flower looks..
- Home
- Product
Ice cream Tub Filling Linear Machine
Model : LTF 30 P
Automatic Filler for multi flower sundae ice cream in plastic tubs.
Ice cream Tub Filling Linear Machine
Model : LTF 30 P
Features
-
PLC controlled operations and it is a fully automatic machine.
- All contact parts are of SS 304 food grade material
- Single & Double track models
- Suitable for films from reel or pre-cut lids.
Basic Functions
- Automatic / Manual Tub Release
- Sensing
- Filling
- Chocolate topping - optional
- Dry nut topping - optional
- Automatic / Manual Lid Placing
- Automatic / Manual Lid Pressing
- Ejecting
Specifications
- Machine Type: Linear , Single head filling , plate indexing type
- Product: Ice cream
- Application: To fill and pack ice cream in tubs
- output capacity : 700 to 1800 tubes per hour
- Filling : By Continuous Freezer
- Filling Quantity: Up to 1 liter tubs
- Filling Accuracy: Depends 100% upon the continuous freezer output
- PLC : Allen Bradley Make
- HMI : Allen Bradley Make
- Pneumatic Parts : Festo
- Power requirement : 1.5 kw
- Electrical Supply : 3 Phase with earthing and neutral
- Air Supply : Approximately 800-liter / min at 6 bar
- Base Structure : S.S. square pipe
- Side guard : S.S. 304
- Panel : S.S. 304
- Contact parts : Food grade material or S.S. 304
- Base : Adjustable Ballfeet
